Pallet Racking

Pallet Racking has been in use since the 1920’s and evolved from the invention of the first forklift in 1915, this allowed warehouses to build upward rather than outward.

Today Selective Pallet Racking is the most basic and cost effective way of storing palletized goods effectively and efficiently.

Selective Racking is the most common form of Pallet Racking in Australia and is normally configured using 838mm wide frames, this frame width is to allow for the Australian Standard Pallet size of 1165mm x1165mm to nest correctly in between the cross beams of the racking system.

Beam Connector side
Beam Connector back
Beam Connector Front

Dickman Pallet Racking & Shelving stock New and Used Pallet Racking only supplying Pallet Racking that is 100% AS4084:2012 Australian Standards tested and certified and we use only Licensed Racking Installers whom are BSA registered in Queensland for all our installations.
Pallet Racking Safety Audits should be carried out annually as per Australian Standards.

Standards Australia logo

Pallet Racking Frames

Our frames are DEXION Equivalent and use the 76.2mm pitch upright allowing the beam heights to be adjusted to the exact required pallet height and this pitch is the most common in the Australian marketplace over the last 30 years.

The dickman profile of 90mm x 67mm x 2.0mm and a HD foot plate spec is applied to all our Pallet Racking frames, this ensures our frames not only meet & exceed AS4084 standards but have an 11,000kg+ bay load rating allowing for multiple beam levels of the same capacity throughout the system.

76.2mm Pitch
Upright Column

Upright Profile
Section

Beam Connector

Part Number Description Size Availability Frame Price
PRF3048 Upright Frame (Blue) with Std Baseplate 3048mm X 838mm (90* 67* 2.0) IN STOCK POA
PRF3658 Upright Frame (Blue) with HD Baseplate 3658mm X 838mm (90* 67* 2.0) IN STOCK POA
PRF4267 Upright Frame (Blue) with HD Baseplate 4267mm X 838mm (90* 67* 2.0) IN STOCK POA
PRF4877 Upright Frame (Blue) with HD Baseplate 4877mm X 838mm (90* 67* 2.0) IN STOCK POA
PRF6096 Upright Frame (Blue) with HD Baseplate 6096mm X 838mm (90* 67* 2.0) IN STOCK POA

Please Note:

All FRAMES are sold in UN-assembled component form, this is for freight cost purposes.

Frames can be Assembled by us for a small labour fee and shipped if required.

Other frame heights and upright profiles available upon request.

4x Floor fixings ( Dyna Bolts ) per frame are included with all Pallet Racking frames supplied.

• Dickman pallet racking can arrange an Installation of a Pallet Racking System using our trusted licensed installers.

A Safe Working Loads SWL sign is required to be completed and attached to all newly installed racking runs.

Pallet Racking Beams

Single Pallet Beam

PRB1372$40 +GST

Standard Double Pallet Beam

PRB2591$58 +GST

Extended Double Pallet Beam

PRB2743$60 +GST

Cross beams are normally configured using a 2591mm beam ( 8.5 ft or 102 inches ), this beam width is to allow for 2x Australian Standard Pallets to rest side by side and have the correct clearances between them.

Cross beams are made from mild steel and are folded into a box shape and powder coated. Our box beams have a per pair maximum capacity of 2000kg – 3000kg this is to suit a pallet weight of up to 1000kg – 1500kg.



Part Number Description Size Capacity Availability Price
PRB1372 Single Pallet Box Beam (RAL2004 ORANGE) 1372mm (60* 50* 1.5) 1500KG IN STOCK $40+GST
PRB2591 Standard Double Pallet Box Beam (RAL2004 ORANGE) 2591mm (100* 50* 1.5) 2400KG IN STOCK $58+GST
PRB2591HD Standard Double Pallet HD Box Beam (RAL2004 ORANGE) 2591mm (110* 50* 1.5) 2700KG IN STOCK POA
PRB2743 Extended Double Pallet Box Beam (RAL2004 ORANGE) 2743mm (100* 50* 1.5) 2100KG IN STOCK $60+GST
PRB2743HD Extended Double Pallet HD Box Beam (RAL2004 ORANGE) 2743mm (110* 50* 1.5) 2500KG IN STOCK POA
PRB3048 Extra Long HD Box Beam (RAL2004 ORANGE) 3048mm (110* 50* 1.5) 2200KG IN STOCK POA
PRB3810 Triple Pallet HD Box Beam (RAL2004 ORANGE) 3810mm (130* 50* 1.5) 2200KG IN STOCK POA
*Capacity per beam pair UDL

Please Note:

All BEAMS are supplied with 2x safety locking clips included in the cost of the beam.

Beam capacities listed are based on a beam pair with a Uniformly Distributed Load UDL.

Other Beam sizes and Beam profiles available upon request.

• Dickman can arrange an Installation of a Pallet Racking System using our trusted licensed installer.

A Safe Working Loads SWL sign is required to be completed and attached to all newly installed racking runs.

Starter Bay & Add On Bay Examples

8 x Pallet Starter Bay

Frame: 2 x PRF4877
Beams: 6 x PRB2591

8 x Pallet Add On Bay

Frame: 1 x PRF4877
Beams: 6 x PRB2591

10 x Pallet Starter Bay

Frame: 2 x PRF6096
Beams: 8 x PRB2591

10 x Pallet Add On Bay

Frame: 1 x PRF6096
Beams: 8 x PRB2591

SECOND HAND PALLET RACKING

We stock and source the below brands of certified Used Pallet Racking:

  • Genuine Dexion
  • SSI Schaefer
  • Colby
  • Stow
  • Space Rack
  • Mac Rack
  • APC
  • Brownbuilt



Please send your used Racking requirements to : dennis@dickmanracking.com.au

Nobody knows New & Used Pallet Racking & Shelving like Dickman Racking.
We also know you want it at the best possible price!
